Scope Sight Reticles

Our scope sight reticles are designed with precision and versatility in mind, making them essential components in a wide range of optical systems. From specialized sporting rifle scopes to advanced surveillance and research instruments, we provide customizable reticle designs tailored to specific needs, such as rangefinding, ballistic compensation, and first focal plane scopes.
We offer a variety of cutting-edge solutions, including diffractive grating reticles, first focal plane reticles, and doublet designs featuring our unique Shielding Technology. With line widths as small as 0.7µm and line accuracy within ±0.2µm, our reticles deliver unmatched precision. Built to withstand extreme environments, our reticles are capable of meeting the most stringent ISO 10110 and MIL-PRF-13830B quality standards.
For applications demanding superior optical performance and complete customization, our reticles offer the ultimate solution, ensuring accuracy and reliability in any setting.

Features and Capabilities:
Diffractive Grating Reticles
Regular Chrome Structure
Night Vision Etch & Fill Structure
Chrome Structure and Etch & Fill Structure on ONE Reticle
First Focal Plane Reticles
Doublet Design available with our Unique Shielding Technology
Broadband Anti-Reflective Coating: Ravg<0.3% @ 400–700nm
Chrome Coating:
     Optical Density (OD)>5,
     Low Reflectivity (R)<5%,
     Transmission (T)<0.001%
Minimum Etch & Fill Structure Line Width: 2µm
Minimum Chrome Structure Line Width: 0.7µm
Line Accuracy: <±0.2µm
Surface Imperfections: 0 Grade; Capable of Achieving the most Stringent ISO 10110 and MIL-PRF-13830B Surface Quality Requirements
Durability: Conforms to MIL-PRF-13830B Standard
Extended Temperature Range for Doublet Reticles: -45°C ~ 70°C
Fully Customizable Graphics
